Managed Systems Configuration Guide

Chapter 3: ProLiant Linux Server Configuration

Note: You can also edit the snmpd.conf file in a text editor if you are not using SMH.

Verifying Connectivity to the CMS

Use the following procedures to verify connectivity to the CMS.

Sending an SNMP Test Trap to the CMS

You can use the SMH interface following the directions in "Configuring SNMP" on page 34 and clicking

Send Trap on the Settings tab. Or, enter the following command on the command line to send a test trap

to the CMS:

snmptrap -v 1 -c public [CMS IP Address] .1.3.6.1.4.1.232 [Linux managed

system IP Address] 6 11003 1234 .1.3.6.1.2.1.1.5.0 s test

.1.3.6.1.4.1.232.11.2.11.1.0 i 0 .1.3.6.1.4.1.232.11.2.8.1.0 s [provide

your own identifiable identifier and time stamp]

The resulting text with details of the managed system and CMS should be returned.

Management Agents Test Trap sent - [timestamp]

Reviewing Test Events Sent from Managed Systems

Some managed system types allow you to send a test event, trap, or indication to the CMS. After you

configure your managed system and send a test event, trap, or indication to the CMS, use the following

process to find the test event, trap, or indication on the CMS.

1. Log on to System Event Analyzer (SEA):

a. On the CMS, click Start → Programs → Hewlett-Packard Service Tools → System Event

Analyzer → System Event Analyzer.

HP Insight Remote Support Advanced (A.05.80)Page 36 of 204
