A.05.80 HP Insight Remote Support Advanced Managed Systems Configuration Guide (June 2013)

Managed Systems Configuration Guide
Chapter 2: ProLiant Windows Server Configuration
Note: You will need to complete the preceding steps for each Windows ProLiant managed system
that will communicate to the CMS through SNMP.
Verifying Connectivity to the CMS
Use the following procedures to verify connectivity to the CMS.
Sending a WBEM Test Indication to the CMS
1. In a Web browser, access the System Management Homepage (SMH) on the managed system:
https://ipaddress:2381.
2. Log on using the administrator user name and password for the managed system.
Note: If you are not prompted for a logon, check the upper right corner of the SMH interface and
click the Sign In link. If you are not logged in as an administrator for the managed system you will
not have all of the relevant configuration options.
3. Click the Settings tab.
4. If you chose to install WBEM with PSP, it will be set as your Data Source, click the Send Test
Indication option.
HP Insight Remote Support Advanced (A.05.80)Page 30 of 204
