Managed Systems Configuration Guide

Chapter 1: Insight Remote Support Advanced Managed Systems Overview

Hardware

Platform

Required

Protocols and

Components Notes

Networking

SAN Switches SNMP Configuration collections are not available for some switch

models except when they are part of a SAN collection. (See

"Table 1.2. Required Protocols and Components for SAN

Services Devices" below.)

See "SAN Switch Configuration" on page 179.

E-Series

Switches

SNMP and

Telnet or SSH

See "E-Series Switch Configuration" on page 187.

A-Series

Switches

SNMP and

Telnet or SSH

Configuration collections are not supported.

See "A-Series Switch Configuration" on page 189.

Power and Cooling Devices

HP Rack-

mountable and

Tower UPS

SNMP Configuration collections are not supported.

See "UPS Network Module Configuration" on page 192.

HP Modular

Cooling System

SNMP Configuration collections are not supported.

See "Modular Cooling System Configuration" on page 196

Table 1.2. Required Protocols and Components for SAN Services Devices

Hardware

Platform

Required Protocols and

Components Notes

Servers

Windows HP Asset (WMI/DCOM)

Linux Telnet, SSH Password or SSH

certificate

HP-UX Telnet, SSH Password or SSH

certificate

OpenVMS Telnet

Tru64 Telnet, SSH Password or SSH

certificate

AIX Telnet, SSH Password or SSH

certificate

Solaris Telnet, SSH Password or SSH

certificate

HP Insight Remote Support Advanced (A.05.80)Page 22 of 204
