Chapter 25
Modular Cooling System Configuration
Modular Cooling Systems are monitored through the management module that is installed on the Modular
Cooling System.
Important: Configuration collections are not supported.
Prerequisites
l Verify the monitored devices are supported by checking the Insight Remote Support Advanced
Release Notes.
l Configure SNMP on the Modular Cooling System.
l Set the Hosting Device as a trap receiver.
l Discover the Modular Cooling System management module.
l Send a test trap to verify connectivity from the monitored devices to the Hosting Device.
Use HP Systems Insight Manager to:
l Discover management modules. As part of the discovery process, HP SIM can detect an installed
management module. The web interface for the discovered module can be launched from the HP SIM
Servers Links tab.
l Receive SNMP traps from the management module. The management module can send event-based
traps to HP SIM that include a URL in the trap. This functionality enables administrators to easily
launch the web interface of the management module in context. For example, if the management
module detects an alarm condition, the management module can send a trap to HP SIM with an
attached hyperlink that routes users directly to the web interface for the attached management module.
l Conveniently launch the management module web interface from within HP SIM.
n Tools menu—You can add a link to the web interface on the HP SIM Tools menu using a tools
definition file.
n Servers Links tab—The web interface can be launched from the HP SIM Servers Links tab.
n Event-based trap—A URL is included in each trap to link directly from HP SIM to the web interface
for the specific device for which the trap was sent.
The management module can be configured to send alert traps to Systems Insight Manager, and other
SNMP management applications.
Configure SNMP
SNMP must be configured on the Modular Cooling System so that Insight Remote Support Advanced can
communicate with it.
To configure SNMP, complete the following steps:
HP Insight Remote Support Advanced (A.05.80)Page 196 of 204
