Chapter 24: UPS Network Module Configuration
3. Select the SNMP version from the SNMP Version drop-down list.
4. Fill in the appropriate fields.
5. Click Save.
For more details about configuring SNMP, see the HP UPS Network Module User Guide located at
http://www.hp.com/support/HPNM_Manuals.
Configure SNMP Trap Receivers
Set the Hosting Device as a trap receiver UPS Network Module web interface. The Trap Receiver
Settings screen allows an administrator to configure management applications to receive SNMP traps
from the UPS Network Module. SNMP management applications, such as Insight Remote Support
Advanced, can receive notifications from the UPS Network Module.
To configure the Hosting Device as an SNMP trap recipient, complete the following steps:
1. Log on to the UPS Network Module web interface.
2. In the left menu, click Notified Applications, then click Add Trap Receiver. Up to three
applications can be configured to receive SNMP traps from the UPS Network Module.
