Chapter 23

A-Series Switch Configuration

Important: Due to a defect in HP SIM 6.3, the A7510E and A5120EL A-Series switches require HP

SIM 7.0 to be supported with Insight Remote Support Advanced.

Configure Telnet or SSH

To configure trap destinations to point to Insight Remote Support Advanced, you need to use Telnet or

SSH (or use a serial console) to access the CLI. Use the below procedures to configure Telnet or SSH.

Setup Telnet

From a serial console, do the following:

1. Enter system view, and enable the Telnet service.

[Sysname] system-view

[Sysname] telnet server enable

2. Configure an IP address for VLAN interface 1. This address will serve as the destination of the Telnet

connection.

[Switch] interface vlan-interface 1

[Switch-Vlan-interface1] ip address 1.2.3.4 255.255.255.0

[Switch-Vlan-interface1] quit

3. Set the authentication mode for the user interfaces to AAA.

[Switch] user-interface vty 0 4

[Switch-ui-vty0-4] authentication-mode scheme

4. Enable the user interfaces to support Telnet.

[Switch-ui-vty0-4] protocol inbound telnet

[Switch-ui-vty0-4] quit

5. Create local user manager, and set the user command privilege level to 3.

[Switch] local-user manager

[Switch-luser-client001] password simple aabbcc

[Switch-luser-client001] service-type telnet

[Switch-luser-client001] authorization-attribute level 3

[Switch-luser-client001] quit

Setup SSH Version 2

From a serial console, do the following:

HP Insight Remote Support Advanced (A.05.80)Page 189 of 204
