Managed Systems Configuration Guide

Chapter 21: SAN Switch Configuration

n View the list of the compiled MIBs:

> dir c:\program files\hp\systems insight manager\MIBs\ *.cfg

n View the MIBs which are registered and preloaded by HP SIM at installation.

Note: The cfglist can also be edited and used to register a set of MIBs.

> dir c:\program files\hp\systems insight manager\MIBs\cfglist*.list

> type c:\program files\hp\systems insight manager\MIBs\cfglistn.list

(where n is the latest version of the file)

n Compile the new Brocade MIBs:

i. Copy the Brocade *.MIB files to c:\program files\hp\systems insight

manager\MIBs directory.

ii. CD to c:\program files\hp\systems insight manager\MIBs.

The following is an example of compiling one of the Brocade MIBs, called SW_v5_7.mib:

>mcompile SW_v5_7.mib

HP Systems Insight Manager Mib Compiler, Version 5.0.2.1 Copyright (c)

2003-2006 Hewlett Packard Corporation

Compiling SW_v5_7.mib Processing import file: SNMPv2-TC.mib Processing

import file: SNMPv2-SMI.mib

Processing import file: Brocade-TC.mib

Processing import file: Brocade-REG-MIB.mib

Mib Compilation completed successfully

>dir SW_v5_7.cfg

Volume in drive C is PrimaryOS Volume

Serial Number is 44E8-FB7E

Directory of C:\Program Files\HP\Systems Insight Manager\mibs

09/07/2008 11:50 AM 84,211 SW_v5_7.cfg ! new compiled MIB with .cfg ex

tension

1 File(s) 84,211 bytes 0 Dir(s) 1,690,189,824 bytes free

n Register the MIB into the SIM database:

>mxmib -a SW_v5_7.cfg

IMPORTING CFG SW_v5_7.cfg COMMAND COMPLETED SUCCESSFULLY

n View the list of MIBs currently registered in HP SIM:

>mxmib -l SHOW LIST OF MIBS

asmib.mib atmf.mib avsnmpv1.mib

12. Add the FC switch to HP SIM to verify if it can be accessed:

a. Open HP SIM, and go to Options → Discovery.

b. Select the Manual tab.

c. Enter the IP address of the switch in the box.

HP Insight Remote Support Advanced (A.05.80)Page 183 of 204
