Managed Systems Configuration Guide

Chapter 20: Tape Library Configuration

Testing the Configuration

Note: Do not pull a redundant FRU to test the configuration.

If you have the latest VLS firmware and the latest version of Command View VLS, use the Test SNMP

button provided on the Command View VLS SNMP configuration page to perform an end-to-end test. This

test event will not result in a case being created at HP, but it will create a local email notification as

confirmation that the VLS SNMP and WEBES is configured correctly.

Secure Key Manager Configuration

Configuring HP SIM

1. In HP SIM, discover the device.

2. If the device is discovered as Unknown, go to Edit System Properties.

3. Edit the model to be Secure Key Manager.

4. Edit the device type to be Storage Device.

5. Save the new system properties.

Configuring Secure Key Manager

1. Log on to Secure Key Manager as admin using https://<SKM IP>:9443.

2. Click the Device tab.

3. On the Device Configuration pane, expand the SNMP option.

4. In Agent, select the Enable SNMP Traps check box.

5. Under Communities and Hostnames, add Public, and allow access to the Enterprise and Standard

MIB's.

6. Under Management Stations, create an SNMPv1 trap, port 162 entry for the IP address of the

HP Insight Remote Support Advanced (A.05.80)Page 171 of 204
