Managed Systems Configuration Guide

Chapter 18: Network Storage System Configuration

2. To enter more than one SNMP Manager IP, copy the following lines:

rwcommunity public <Manager IP>

rocommunity public <Manager IP>

trapsink <Manager IP> public

3. After updating the snmpd.conf file, restart the snmpd service:

# service snmpd restart

For more information about the /sbin/hpsnmpconfig script, see “SNMP Configuration” in the hp-

snmp-agents(4) man page. For information about the HP System Management Homepage, see:

http://h18013.www1.hp.com/products/servers/management/agents/index.html.

Important: The /opt/hp/hp-snmp-agents/cma.conf file controls certain actions of the

SNMP agents. You can add a trapIf entry to the file to configure the IP address used by the

SNMP daemon when sending traps. For example, to send traps using the IP address of the eth1

interface, add the following:

trapIf eth1

Then restart the HP SNMP agents:

service hp-snmp-agents restart

For more information about the cma.conf file, see Section 3.1 of the Managing ProLiant servers

with Linux HOWTO at

http://h20000.www2.hp.com/bc/docs/support/SupportManual/c00223285/c00223285.pdf.

Start or Restart Insight Remote Support Advanced

Services

On the Hosting Device, start or restart the following services:

l System Management Homepage:

# service hpsmhd restart

l SNMP Agent:

# service snmpd restart

l HP SNMP Agents:

# service hp-snmp-agents start

To ensure that hp-snmp-agents restarts when the system is rebooted, enter the following

command:

# chkconfig hp-snmp-agents on

HP Insight Remote Support Advanced (A.05.80)Page 158 of 204
