Managed Systems Configuration Guide
Chapter 16: Enterprise Virtual Array Configuration
Configuring EVA-Specific Information on the CMS
Command View EVA Password Configuration
Command View EVA V6 and later uses a secure logon (SSL) design so there is a Windows account
username and password required to access the Command View EVA User Interface, as discussed in
"SMS System and Access Requirements" on page 114. The Command View EVA UI username and
password is also required for WEBES to communicate with the EVA arrays, and must be manually
entered into the Managed Entities screen of the WEBES SEA Web interface before EVA events can be
processed. There are no default values for this username and password. This would be set up by the
System Manager. The account requires a minimum of read access (HP Storage Users) group privilege.
Note:
l HP SIM on the CMS communicates with to the EVA using a WBEM protocol CIMOM provided by
SMI-S on the SMS.
l WEBES on the CMS communicates with ELMC on the SMS, which then communicates with the
EVA using Command View EVA on the SMS.
Refer to Command View EVA installation documentation for setting up a valid SMS and array. Command
View EVA documentation is available at the following URL:
http://h18006.www1.hp.com/products/storage/software/cmdvieweva/index.html (click the HP Support &
Documents link, then the Manuals link to view the list of Command View EVA manuals)
The following documents are required for Command View EVA installation and configuration:
l HP StorageWorks Command View EVA Installation Guide
l HP StorageWorks Command View EVA Release Notes
l HP StorageWorks Enterprise Virtual Array Compatibility Reference
Setting up a Trust Relationship Between the SMS and the
CMS
1. Set up a Trust Relationship between the SMS and the CMS:
Note: This Trust Relationship allows for HP SIM links to Command View EVA array pages to be
displayed back on the CMS.
Setting up such a Trust Relationship is not a requirement. However, the trust relationship allows
the user to launch Command View EVA from HP SIM.
a. Using the Command View EVA UI, select the Server Options link in the upper right corner of the
page. This opens the Management Server Options page.
b. Select System Insight Manager/Replication Solutions Manager trust relationships. This
opens the SIM/RSM Trust Relationship page.
