Managed Systems Configuration Guide

Chapter 16: Enterprise Virtual Array Configuration

Note: In the example above SMI-S is configured to use ports 5988 and 60000.

Resetting the Port Numbers when Command View

EVA was Installed before HP SIM

1. Edit the file:

C:\Program Files\Hewlett-Packard\SMI-S\CXWSCimom\config\cxws.properties

2. Locate the cxws.http.port and cxws.https.port entry and reset it to these values:

cxws.http.port=5988

cxws.https.port=60000

3. Restart HP StorageWorks CIM Object Manager

Note: Any API that requires communication to the arrays through this SMI-S will also have to have

the target port updated as well. In a separate SMS configuration, Command View EVA should operate

using the default ports 5988 and 5989 with the Insight Remote Support Advanced as long as there are

no other port conflicts on the SMS.

Command View EVA Hosted on a Separate SMS

Use this section and subsections for guidance in configuring an SMS separate from the CMS.

The following software applications are hosted on the SMS and are related to or part of the Insight Remote

Support Advanced solution:

l Command View EVA

l Event Log Monitoring Collector (ELMC), formerly called WCC Proxy

l MC3 Components

Starting with Command View EVA 8.0, the software components HP StorageWorks SMI-S CIMOM and

HP StorageWorks SMI-S EVA are no longer visible in the Add/Remove Programs window. Verify the

component is installed and running by checking the presence and status of the Service named HP

StorageWorks CIM Object Manager. Verify that your SMS has Command View EVA 7.0.1 or higher

installed, as well as the SMI-S EVA and SMI-S CIM components (that is, the two components that

comprise SMI-S). Go to the Windows Control Panel on the SMS and verify that the following components

are listed in the Add/Remove Programs dialog:

l HP StorageWorks Command View EVA

l HP StorageWorks SMI-S CIMOM

l HP StorageWorks SMI-S EVA

Caution: Removing SMI-S from a host system also forces the removal of Command View for Tape

Libraries (TL). The version of Command View TL must match the firmware used in the library.

HP Insight Remote Support Advanced (A.05.80)Page 112 of 204
