Chapter 16: Enterprise Virtual Array Configuration
l "Command View EVA 8.0.1 and Higher Hosted on the CMS" below
l "Command View EVA Hosted on a Separate SMS" on page 112
l "Requirements to Support EVA4400 and P6000 with Command View EVA on the ABM" on page 124
l "Troubleshooting EVA Managed Systems" on page 128
Command View EVA 8.0.1 and Higher Hosted on
the CMS
Use this section if you choose to host your Command View EVA 8.0.1 software on the Central
Management Server (CMS). If you want to host your current Command View EVA software on a separate
SMS server or you want to use Command View EVA 8.0 or earlier, then you must install Command View
EVA on that separate SMS device and should skip to "Command View EVA Hosted on a Separate SMS"
on page 112.
The following content is an excerpt from the HP StorageWorks Command View EVA and HP Systems
Insight Manager installation instructions. To install HP Command View EVA 8.0.1 and HP SIM on the
same server, follow these instructions.
Before performing these installation procedures, verify the following CMS requirements are met:
l A supported version of Microsoft Windows is installed.
l HP Command View EVA has not previously been installed.
l Windows security patches for SP2 have been installed.
Important Port Settings Information
The default port assignment of 5989 for WBEM/WMI and SMI-S has led to conflicts with HP SIM on the
CMS. The WEBES subcomponent's ability to interface with WBEM indications, WMI Mapper, and
inclusion of HP-UX systems to the environment add more complexity to configuring the environment. HP-
UX is hard coded to use port 5989. The following sections describe changes that address the port
assignment issues and provide a new solution for configuring Insight Remote Support Advanced with
Command View SMI-S.
Note: If your Insight Remote Support Advanced environment is already configured and working, you
may choose to leave things as they are and plan to implement the following steps only if you start to
see related problems.
The sequence of installation for HP SIM and Command View SMI-S on a CMS will impact the default
ports settings. The current best practices suggestion is to install HP SIM first and allow WMI Mapper to
use the default of port 5989. The Command View EVA install will detect if the port is being used and use a
different port instead.
Assess your current port assignments in your environment from a command window by executing the
following command:
C:\ netstat –anb >netstat.txt
