HP Insight Management WBEM Providers 9.4 for Microsoft Windows Data Sheet

Table 4-13 Class: HP_RealizesPowerSupply
Property name
Property implementation
Antecedent
References HP_PowerSupplyModule
Dependent
References HP_PowerSupply
4-3-13 HP_SystemPhysicalPowerSupply
Table 4-14 Class: HP_SystemPhysicalPowerSupply
Property name
Property implementation
GroupComponent
References HP_ComputerSystemChassis
PartComponent
References HP_PowerSupplyModule
4-3-14 HP_PowerMeter
HP_PowerMeter is used to model the power consumption within power supplies on ProLiant Servers.
The Windows®-specific implementation class is HP_WinPowerMeter. Not all systems support
reporting power consumption information.
NOTE: Power supply numbers for existing instances do not change when other power supplies are
added and removed.
Table 4-15 Class: HP_PowerMeter
Property name
Property implementation
CIM_ManagedElement
Caption
Power Meter n, where n represents the number of the
power meter instance
Description
Power Meter n provides power monitoring for Power
Supply m where n represents the number of the power
meter instance and m represents the power supply
instance
ElementName
Power Meter n, where n represents the number of the
power meter instance
CIM_Managed SystemElement
OperationalStatus[0]
2 (OK)—If power consumption reported by the sensor
is within normal operating range
StatusDescriptions[0]
―Power consumption reported by the sensor is within
normal operating range‖—if temperature reported by
the sensor is within normal operating range
