HP Insight Management WBEM Providers 9.4 for Microsoft Windows Data Sheet

Table 4-11 Class: HP_PowerSupplySlot
Property name
Property implementation
CIM_PhysicalElement
CreationClassName
―HP_PowerSupplySlot‖
Tag
Power Supply n, where n represents the physical bay
number
Description
Power Supply n, where n represents the physical bay
number
ElementName
Power Supply n, where n represents the physical bay
number
CIM_PhysicalConnector
ConnectorLayout
7 (Slot)
ConnectorPinout
―Custom Power Bay‖
ConnectorType
76 (Proprietary)—Custom Power Supply slot
CIM_Slot
Number
The physical power supply bay number
SupportsHotPlug
 true—if slot supports hot plug operations
 false—if slot does not support hot plug operations
VendorCompatibilityStrings
―HPQ:PowerSupply‖
HP_PowerSupplySlot
4-3-11 HP_PowerSupplyInSlot
HP_PowerSupplyInSlot is used to represent an association between HP_PowerSupplyModule and
HP_PowerSupplySlot that contains this Power Supply.
Table 4-12 Class: HP_PowerSupplyInSlot
Property name
Property implementation
Antecedent
References HP_PowerSupplySlot
Dependent
References HP_PowerSupplyModule
4-3-12 HP_RealizesPowerSupply
HP_RealizesPowerSupply is used to represent an association between HP_PowerSupply and
HP_PowerSupplyModule that realizes this power supply.
