23-3-31 HP_SATALogicalPortISATAProtocolEndpoint (Association)
Table 23-23 Class: HP_SATALogicalPortISATAProtocolEndpoint (CIM_DeviceSAPImplementation)
Property name
Property implementation
Antecedent
HP_SATALogicalPort
Dependent
HP_ISATAProtocolEndpoint
23-3-32 HP_SATAInitiatorTargetLogicalUnitPath
The following class instance is created to represent the path from disk to controller.
Table 23-24 Class: HP_SATAInitiatorTargetLogicalUnitPath(CIM_SCSIInitiatorTargetLogicalUnitPath)
Property name
Property implementation
Initiator
HP_ISATAProtocolEndpoint
Target
HP_TSATAProtocolEndpoint
LogicalUnit
HP_SATAStorageExtent
State
2 (active)
23-3-33 HP_SATAStorageCollectionSATADiskDrive (Association)
Table 23-25 Class: HP_SATAStorageCollectionSATADiskDrive (CIM_MemberOfCollection)
Property name
Property implementation
Collection
HP_SATAStorageCollection
Member
HP_SATADiskDrive
23-3-34 HP_SATAHostedCollection (Association)
Table 23-26 Class: HP_SATAHostedCollection (HP_GroupHostedCollection)
Property name
Property implementation
Antecedent
HP_WinComputerSystem
Dependent
HP_SATAStorageCollection
