HP Insight Management WBEM Providers 9.4 for Microsoft Windows Data Sheet

HP Confidential
23-3-27 HP_SATADiskPhysicalPackageSATADiskDrive
(Association)
Table 23-19 Class: HP_SATADiskPhysicalPackageSATADiskDrive (CIM_Realizes)
Property name
Property implementation
Antecedent
HP_SATADiskPhysicalPackage
Dependent
HP_SATADiskDrive
23-3-28 HP_SATADiskPhysicalPackageSATADiskLocation
(Association)
Table 23-20 Class: HP_SATADiskPhysicalPackageSATADiskLocation (CIM_PhysicalElementLocation)
Property name
Property implementation
Element
HP_SATADiskPhysicalPackage
PhysicalLocation
HP_SATADiskLocation
23-3-29 HP_SATADiskDriveDiskDriveFW (Association)
Table 23-21 Class: HP_SATADiskDriveDiskDriveFW (CIM_ElementSoftwareIdentity)
Property name
Property implementation
Antecedent
HP_SATADiskDriveFW
Dependent
HP_SATADiskDrive
ElementSoftwareStatus
 ElementSoftwareStatus[0]: 2 (Current)
 ElementSoftwareStatus[1]: 6 (Installed)
23-3-30 HP_TSATAProtocolEndpointSATADiskDrive (Association)
Table 23-22 Class: HP_TSATAProtocolEndpointSATADiskDrive (CIM_SAPAvailableForElement)
Property name
Property implementation
AvailableSAP
HP_TSATAProtocolEndpoint
ManagedElement
HP_SATADiskDrive
