HP Insight Management WBEM Providers 9.4 for Microsoft Windows Data Sheet

HP Confidential
Table 23-8 Class HP_SATAPortControllerBIOS(HP_SoftwareIdentity)
Property name
Property implementation
CIM_LogicalElement
CIM_SoftwareIdentity
ClassificationDescriptions
Same as caption
Classifications
6 (Firmware/BIOS)
IsEntity
False(always set to False)
IdentityInfoType
CIM:SoftwareFamily
IdentityInfoValue
HPQ:<PNPDeviceID assigned to Controller>
InstanceID
Opaque key
Manufacturer
Standard IDE ATA/ATAPI controllers BIOS (for
pciide.sys and atapi.sys)
Standard SATA controllers BIOS (for msahci.sys)
VersionString
Same as HP_SATAPortControllerControllerVersion
property
23-3-17 HP_WinComputerSystemSATAPortController
(Association)
Table 23-9 Class: HP_WinComputerSystemSATAPortController (CIM_SystemDevice)
Property name
Property implementation
GroupComponent
HP_WinComputerSystem
PartComponent
HP_SATAPortController
23-3-18 HP_SATAPortControllerSATALogicalPort (Association)
Table 23-10 Class: HP_SATAPortControllerSATALogicalPort (CIM_ControlledBy)
Property name
Property implementation
Antecedent
HP_SATAPortController
Dependent
HP_SATALogicalPort
23-3-19 HP_SATAPortControllerPhysicalPackageSATAControllerLo
cation (Association)
