HP Insight Management WBEM Providers 9.4 for Microsoft Windows Data Sheet

HP Confidential
Table 18-12 Class: HPFCHBA_SCSIProtocolController
Property name
Property implementation
CIM_ManagedSystemElement
OperationalStatus[0]
 1 (Other)
 2 (OK)
 3 (Degraded)
 6 (Error)
CIM_LogicalElement
CIM_EnabledLogicalElement
EnabledDefault
2 (Enabled)
EnabledState
5 (Not Applicable)
RequestedState
12 (Not Applicable)
CIM_LogicalDevice
CreationClassName
HPFCHBA_SCSIProtocolController
DeviceID
PortWWN
SystemName
HPQ:GUID: 85408DBD-6A39-41CD-9E5A-
357AEA130BBF:NODEWWN:nodewwn:PORTWWN:
portwwn, where nodewwn is the node‘s WWN and
portwwn is the port‘s WWN
SystemCreationClassName
HPFCHBA_ComputerSystem
CIM_ProtocolController
MaxUnitsControlled
255
CIM_SCSIProtocolController
18-3-12 HPFCHBA_SCSIProtocolEndpoint
HPFCHBA_SCSIProtocolEndpoint represents SCSI protocol running through a port.
Table 18-13 Class: HPFCHBA_SCSIProtocolEndpoint
Property name
Property implementation
CIM_ManagedElement
ElementName
SCSI Protocol Endpoint
CIM_ManagedSystemElement
Name
PortWWN
CIM_LogicalElement
CIM_EnabledLogicalElement
