HP Insight Management WBEM Providers 9.4 for Microsoft Windows Data Sheet

3 CPU
3-1 Overview
The following profiles are implemented, and the following files are installed by this provider.
Table 3-1 Overview
Implemented Profiles
 HP CPU Profile (P00106)
 HP CPU Consolidated Status Profile (P00107)
 HP CPU Physical Asset Profile (P00108)
 HP Location Profile (P00124)
Provider Installation Files
 HPWmiProc.dll
 HPWmiProcEvt.dll
 HPWmiProcEvtMsg.dll
3-2 Use cases
For use cases, see HP CPU Profile (P00106), HP CPU Consolidated Status Profile (P00107), HP CPU
Physical Asset Profile (P00108), and HP Location Profile (P00124).
3-3 Class implementations
The following classes describe the CPU implementation.
3-3-1 HP_Processor
HP_Processor extends the class CIM_Processor to model system processors.
The following properties are implemented.
Table 3-2 Class: HP_Processor Properties
Property name
Property implementation
CIM_ManagedElement
Caption
 Processor in slot a, where a is the slot number
 Processor in socket b, where b is the socket number
 Processor in slot a socket b, where a is the slot
number and b is the socket number
