Table 17-40 Class: HPSCSI_DriveCageDiskDrive (CIM_Container)
Property name
Property implementation
GroupComponent
HPSCSI_DriveCage
PartComponent
HPSCSI_DiskPhysicalPackage
17-3-40 HPSCSI_HBAComputerSystemHBAFirmwareIdentity
(Association)
Table 17-41 Class: HPSCSI_HBAComputerSystemHBAFirmwareIdentity (CIM_InstalledSoftwareIdentity)
Property name
Property implementation
Antecedent
HPSCSI_HBAFirmwareIdentity
Dependent
HPSCSI_HBAComputerSystem
ElementSoftwareStatus
 ElementSoftwareStatus[0]: 2 (Current)
 ElementSoftwareStatus[1]: 6 (Installed)
17-3-41 HPSCSI_SCSIProtocolControllerStorageVolume
(Association)
Table 17-42 Class: HPSCSI_SCSIProtocolControllerStorageVolume (CIM_ProtocolControllerForUnit)
Property name
Property implementation
Antecedent
HPSCSI_HBASCSIProtocolController
Dependent
HPSCSI_StorageVolume
DeviceAccess
2 (Read Write)
DeviceNumber
Device LUN number
17-3-42 HPSCSI_StorageEnclosureProcessorEnclosureFirmware
(Association)
Table 17-43 Class: HPSCSI_StorageEnclosureProcessorEnclosureFirmware (CIM_ElementSoftwareIdentity)
Property name
Property implementation
Antecedent
HPSCSI_EnclosureFirmware
Dependent
HPSCSI_StorageEnclosureProcessor
