HP Insight Management WBEM Providers 9.4 for Microsoft Windows Data Sheet

HP Confidential
Table 17-22 Class: HPSCSI_StorageEnclosureLocation (HP_Location)
Property name
Property implementation
HP_Location
ElementLocationTag
 External for external enclosures
 Internal for drive cages located within the host
chassis
ElementLocationTagDesc
19 (Box)
17-3-22 HPSCSI_DriveCageLocation
HPSCSI_DriveCageLocation represents a location string for the drive cage.
Table 17-23 Class: HPSCSI_DriveCageLocation (HP_Location)
Property name
Property implementation
CIM_ ManagedElement
ElementName
Drive cage location (for example SCSI Port 1)
Caption
Drive cage location
For example, SCSI Port 1
Description
Drive cage location
For example, SCSI Port 1
CIM_Location
Name
Key
PhysicalPosition
Key
HP_Location
ElementLocationTag
Duplex Top, Duplex Bottom, Non Duplex
ElementLocationTagDesc
22 (Drive Cage)
LocationInformation[0]
HBA Port identifier
Examples:
 SCSI Port 1
 SCSI Port 2
LocationInfoDesc[0]
0 (Hood Tag)
17-3-23 HPSCSI_HBALocation
HPSCSI_HBALocation represents a location string for the HBA.
