Table 17-19 Class: HPSCSI_DASCSIProtocolEndpoint (CIM_SCSIProtocolEndpoint)
Property name
Property implementation
ProtocolIFType
0 (Unknown)
CIM_SCSIProtocolEndpoint
ConnectionType
3 (Parallel SCSI)
Role
2 (Initiator)
17-3-19 HPSCSI_HBASCSIProtocolController
HPSCSI_HBASCSIProtocolController represents a view of SCSI resources on the SCSI HBA. This is
required to model the presentation of SCSI LUNs to the host system.
Table 17-20 Class: HPSCSI_HBASCSIProtocolController (CIM_SCSIProtocolController)
Property name
Property implementation
CIM_ManagedElement
ElementName
Controller name and location (for example, SCSI
Controller Port 1 in Slot 4)
CIM_ManagedSystemElement
OperationalStatus[0]
Operational status of the controller
0 (Unknown)
2 (OK)
6 (Error)
CIM_LogicalElement
CIM_EnabledLogicalElement
EnabledDefault
2 (Enabled)
EnabledState
5 (Not Applicable)
RequestedState
12 (Not Applicable)
CIM_LogicalDevice
CreationClassName
HPSCSI_HBASCSIProtocolController
DeviceID
Opaque key
SystemCreationClassName
HPSCSI_HBAComputerSystem
SystemName
HBA index
CIM_ProtocolController
MaxUnitsControlled
15
CIM_SCSIProtocolController
