HP Insight Management WBEM Providers 9.4 for Microsoft Windows Data Sheet

HP Confidential
Table 17-10 Class: HPSCSI_StorageEnclosureProcessor (CIM_ComputerSystem)
Property name
Property implementation
OperationalStatus
Operational status for enclosure and associated power
supplies, fans and sensors.
The use of OperationalStatus is described in the HP
Storage Enclosure Profile. Index values are populated
as follows:
 OperationalStatus[0]—Enclosure status
○ 0 (Unknown)
○ 2 (OK)
○ 3 (Degraded)
○ 6 (Error)
 OperationalStatus [1]—Fan status (See Profile)
 OperationalStatus [2]—Power Supply status (See
Profile)
 OperationalStatus [3]—Temp Sensor Status (See
Profile)
CIM_LogicalElement
CIM_EnabledLogicalElement
EnabledDefault
2 (Enabled)
EnabledState
5 (Not applicable)
RequestedState
12 (Not applicable)
CIM_System
CreationClassName
HPSCSI_StorageEnclosureProcessor
IdentifyingDescriptions
Other Vendor Specific Name
NameFormat
Other
CIM_ComputerSystem
Dedicated[0]
2 (Other)
OtherDedicatedDescriptions[0]
SDE—Indicates Storage Device Enclosure
17-3-10 HPSCSI_HBAPortController
HPSCSI_HBAPortController represents the HBA in the host system. There is one instance per HBA.
Table 17-11 Class: HPSCSI_HBAPortController (CIM_PortController)
Property name
Property implementation
CIM_ManagedElement
