HP Insight Management WBEM Providers 9.4 for Microsoft Windows Data Sheet

HP Confidential
Table 17-4 Class: HPSCSI_DiskDrive (CIM_DiskDrive)
Property name
Property implementation
HP_DiskDrive
DriveConfiguration
4 (Non RAID)
DriveHasMNPData
 True—drive can report MNP Data
 False—drive does not report MNP Data
DriveInterface
1 (Parallel SCSI)
DrivePlacement
 0 (Unknown)—drive placement cannot be
determined
 1 (Internal)—drive is internal to host
 2 (External)—drive is contained in external
enclosure
DriveRotationalSpeed
Speed in rpm
NegotiatedDataWidth
Bus width in bits
NegotiatedSpeed
Current bus speed in bits per second
HPSCSI_DiskDrive
SMARTSupport
Indicates whether the disk supports the SMART feature
or not
Action
Indicates the status of the physical disk
17-3-4 HPSCSI_StorageExtent
HPSCSI_StorageExtent represents the consumable storage that is available on a disk drive. There is
one instance per disk drive.
Table 17-5 Class: HPSCSI_StorageExtent (CIM_StorageExtent)
Property name
Property implementation
CIM_ManagedElement
ElementName
Disk name (for example, SCSIBUS:1 SCSIID:0)
CIM_ManagedSystemElement
Name
Serial number of drive
OperationalStatus[0]
 0 (Other)
 2 (OK)
 5 (Predictive Failure)
 6 (ERROR)
StatusDescriptions
Description about the OperationalStatus
CIM_LogicalElement
CIM_EnabledLogicalElement
