Table 16-55 Class: HPSAS_StorageRedundancySetStorageExtent (CIM_MemberOfCollection)
Property name
Property implementation
Collection
HPSAS_StorageRedundancySet
Member
HPSAS_StorageExtent
16-3-55 HPSAS_ArraySystemFirmware (Association)
Table 16-56 Class: HPSAS_ArraySystemFirmware (CIM_InstalledSoftwareIdentity)
Property name
Property implementation
InstalledSoftware
HPSAS_Firmware
System
HPSAS_ArraySystem
16-3-56 HPSAS_SCSIProtocolControllerStorageVolume
(Association)
Table 16-57 Class: HPSAS_SCSIProtocolControllerStorageVolume (CIM_ProtocolControllerForUnit)
Property name
Property implementation
Antecedent
HPSAS_SCSIProtocolController
Dependent
HPSAS_StorageVolume
DeviceNumber
Logical Disk number as shown by the operating system
for the disk
DeviceAccess
2 (Read Write)
16-3-57 HPSAS_FirmwareArraySystem (Association)
Table 16-58 Class: HPSAS_FirmwareArraySystem (CIM_ElementSoftwareIdentity)
Property name
Property implementation
Antecedent
HPSAS_Firmware
Dependent
HPSAS_ArraySystem
ElementSoftwareStatus
 ElementSoftwareStatus[0]: 2 (Current)
 ElementSoftwareStatus[1]: 6 (Installed)
