Table 16-25 Class: HPSAS_DriveCage (CIM_PhysicalPackage)
Property name
Property implementation
CIM_ManagedElement
ElementName
Port <m> Box <n>, where <m> is the name of the port
this drive cage is connected and <n> is the Box
Number
For example, Port IE Box 1
CIM_ManagedSystemElement
Name
Serial Number of drive cage
N/A—when serial number is not available
CIM_PhysicalElement
CreationClassName
HPSAS_DriveCage
Manufacturer
Drive Cage Vendor string
Model
Drive Cage Model string
PartNumber
N/A–Not available in this implementation
Tag
Opaque key
SerialNumber
Enclosure Serial number
Version
N/A–Not available in this implementation
CIM_PhysicalPackage
RemovalConditions
2 (Not Applicable)
HP_DriveCage
BackplaneSpeed
See profile
DriveBays
See profile
DuplexLocation
See profile
HPSAS_DriveCage
16-3-25 HPSAS_EnclosureFirmware
HPSAS_EnclosureFirmware represents the firmware installed on a MSA Enclosure.
Table 16-26 Class: HPSAS_EnclosureFirmware (CIM_SoftwareIdentity)
Property name
Property Implemenation
CIM_ManagedElement
Caption
Storage Enclosure Firmware
Description
Storage Enclosure Firmware
ElementName
TargetType value
