HP Insight Management WBEM Providers 9.4 for Microsoft Windows Data Sheet

HP Confidential
Table 16-22 Class: HPSAS_DiskDriveLocation (HP_Location)
Property name
Property implementation
HPSAS_DiskDriveLocation
16-3-22 HPSAS_StorageCapabilities
HPSAS_StorageCapabilities represents the possible capabilities of a Storage Pool.
Table 16-23 Class: HPSAS_StorageCapabilities (CIM_StorageCapabilities)
Property name
Property implementation
CIM_ManagedElement
ElementName
 For Primodial Pools
Controller name and location, for example, HP 8
INT Port SAS/SATA HBA in Slot 3 for internal
 For Concrete Pools
Controller name and location:Array identifier, for
example, HP 8 INT Port SAS/SATA HBA in Slot 3:
Storage Pool for internal
CIM_Capabilities
InstanceID
Opaque key
CIM_StorageCapabilities
DataRedundancyDefault
 0 (When Pool is NonRAID)
 1 (When number of drives = 1)
 2 (When number of drives > 1) For example, Pool
can be configured for redundancy.
DataRedundancyMax
 0 (When Pool is NonRAID)
 1 (When number of drives = 1)
 2 (When number of drives > 1) For example, Pool
can be configured for redundancy.
DataRedundancyMin
 0 (When Pool is NonRAID)
 1 (No single point of failure RAID)
DeltaReservationDefault
0
DeltaReservationMax
0
DeltaReservationMin
0
ElementType
5 (Storage Pool)
NoSinglePointOfFailure
 True—When number of drives > 1 (For example,
Pool can be configured for redundancy.)
 False—When number of drives = 1 or Pool is
NonRAID
