HP Insight Management WBEM Providers 9.4 for Microsoft Windows Data Sheet

Table 2-22 HP_SystemHardwareIndication: DL980 System configuration (current 40-bit addressing mode) is
not optimal
Property name
Property implementation
CIM_AlertIndication
Description
The system is not configured for optimal performance
as its address mode is currently set to 40-
bit instead of the Windows recommended 44-bit mode.
In addition to the larger addressable physical
address space, the 44-bit mode improves the system
performance by generating less address decoding
faults. Reporting Entity: McHealthProvider Service
Event Timestamp: <EventTimeStamp>
Where <EventTimeStamp> is the date and time of the
indication
AlertType
5 (Device Alert)
EventID
8002
EventTime
Time of the event or time of the indication if event time
unknown
ProviderName
HP MCHealth
RecommendedActions
Restart system to invoke ROM-Based Setup Utility
(RBSU) and select <Advanced Options>, <Advanced
System ROM Options>, <Address Mode 44-bit> to
change the Address Mode from 40-bit to 44-bit.
\n\nNote: Before changing the address mode to 44-
bit please ensure that the Microsoft QFE 980598 is
installed on the system, if it has 1TB or more RAM.
SystemName
HP_ComputerSystem.Name
SystemCreationClassName
HP_ComputerSystem.CreationClassName
HP_AlertIndication
Summary
The system configuration should be changed for
optimal performance.
EventCategory
1 (Other)
ProbableCause
1 (Other)
ProbableCauseDescription
ProviderVersion
Provider version generating the indication in the
format, <major>.<minor>.<revision>.<build>
NetworkAddresses
Contains a list of all the IP addresses (IPv4 and IPv6) of
the computer system generating the indication
