Table 16-17 Class: HPSAS_SCSIProtocolEndpoint (CIM_SCSIProtocolEndpoint)
Property name
Property implementation
CIM_ManagedSystemElement
Name
HBA Serial Number
CIM_LogicalElement
CIM_EnabledLogicalElement
EnabledDefault
2 (Enabled)
RequestedState
12 (Not Applicable)
CIM_ServiceAccessPoint
CreationClassName
HPSAS_SCSIProtocolEndpoint
SystemCreationClassName
HPSAS_ArraySystem
SystemName
HPSAS_ArraySystem.Name
CIM_ProtocolEndpoint
ProtocolIFType
0 (Unknown)
CIM_SCSIProtocolEndpoint
ConnectionType
1 (Other)
OtherConnectionType
PCI
Role
4 (Both Initiator and Target)
HPSAS_SCSIProtocolEndpoint
16-3-17 HPSAS_SCSIProtocolController
HPSAS_SCSIProtocolController represents a view of SCSI resources on the controller.
Table 16-18 Class: HPSAS_SCSIProtocolController (CIM_SCSIProtocolController)
Property name
Property implementation
CIM_ManagedElement
ElementName
Controller name and location
For example, HP 8 INT Port SAS/SATA HBA in Slot 3
CIM_ManagedSystemElement
OperationalStatus[0]
Operational status of the controller
 0 (Unknown)
 2 (OK)
 6 (Error)
CIM_LogicalElement
CIM_EnabledLogicalElement
