Table 16-10 Class: HPSAS_PortController (CIM_PortController)
Property name
Property implementation
SystemCreationClassName
HPSAS_ArraySystem
SystemName
HPSAS_ArraySystem.Name
CIM_Controller
CIM_PortController
ControllerType
1 (Other)
OtherControllerType
SAS/SATA
HPSAS_PortController
16-3-10 HPSAS_DAPort
HPSAS_DAPort represents the front-end port for an HBA in the host system. Direct Attached implies
that the array controller is attached to a local bus on the host (for example, PCI).
Table 16-11 Class: HPSAS_DAPort (CIM_DAPort)
Property name
Property implementation
CIM_ManagedElement
ElementName
Controller name and location, for example, HP 8 INT
Port SAS/SATA HBA in Slot 3
CIM_ManagedSystemElement
OperationalStatus[0]
Port status
 0 (Unknown)
 2 (OK)
 6 (Error)
CIM_LogicalElement
CIM_EnabledLogicalElement
EnabledDefault
2 (Enabled)
EnabledState
5 (Not Applicable)
RequestedState
12 (Not Applicable)
CIM_LogicalDevice
CreationClassName
HPSAS_DAPort
DeviceID
Opaque key
SystemCreationClassName
HPSAS_ArraySystem
SystemName
HPSAS_ArraySystem.Name
CIM_LogicalPort
