HP Insight Management WBEM Providers 9.4 for Microsoft Windows Data Sheet

HP Confidential
Table 16-9 Class: HPSAS_DiskPhysicalPackage (CIM_PhysicalPackage)
Property name
Property implementation
Manufacturer
Drive vendor string
Model
Drive model string
PartNumber
N/A—Not available in this implementation
SerialNumber
Drive serial number
Tag
Controller Serial number (SerialNumber:
PhysicalDriveDeviceNumber)
Version
N/A—Not available in this implementation
CIM_PhysicalPackage
HotSwappable
 true—Drive is hot swappable
 false—Drive is not hot swappable
RemovalConditions
 0 (Unknown)
 2 (Not Applicable)
 3 (Removable when off)
 4 (Removable when on or off)
HPSAS_DiskPhysicalPackage
16-3-9 HPSAS_PortController
HPSAS_PortController represent the HBA in the host system. There is one instance per HBA.
Table 16-10 Class: HPSAS_PortController (CIM_PortController)
Property name
Property implementation
CIM_ManagedElement
ElementName
Controller name and location, for example, HP 8 INT
Port SAS/SATA HBA in Slot 3
CIM_ManagedSystemElement
CIM_LogicalElement
CIM_EnabledLogicalElement
EnabledDefault
2 (Enabled)
EnabledState
5 (Not Applicable)
RequestedState
12 (Not Applicable)
CIM_LogicalDevice
CreationClassName
HPSAS_PortController
DeviceID
Controller serial number
