16-3-5 HPSAS_StorageExtent
HPSAS_StorageExtent represents the consumable storage that is available on a disk drive. There is
one instance per disk drive.
Table 16-6 Class: HPSAS_StorageExtent (CIM_StorageExtent)
Property name
Property implementation
CIM_ManagedElement
ElementName
Disk location
For example, Bay: 5
CIM_ManagedSystemElement
Name
Serial number of drive
OperationalStatus[0]
Operational Status for the disk drive
 0 (Unknown)
 2 (OK)
 5 (Predictive Failure)
 6 (Error)
CIM_LogicalElement
CIM_EnabledLogicalElement
EnabledDefault
2 (Enabled)
EnabledState
5 (Not Applicable)
RequestedState
12 (Not Applicable)
CIM_LogicalDevice
CreationClassName
HPSAS_StorageExtent
DeviceID
Opaque ID
SystemCreationClassName
HPSAS_ArraySystem
SystemName
HPSAS_ArraySystem.Name
CIM_StorageExtent
BlockSize
Block size in bytes
ConsumableBlocks
Total number of blocks on disk drive
ExtentStatus[0]
Indicates extended status for the disk drive
 2 (None)
 11 (Rebuild – disk drive is currently rebuilding
data)
NumberOfBlocks
Total number of blocks on disk drive
Primordial
Set to True
HP_StorageExtent
