HPSAS_ArraySystem represents the top-level system. There is one instance per HBA.
Table 16-2 Class: HPSAS_ArraySystem (CIM_ComputerSystem)
Property name
Property implementation
CIM_ManagedElement
ElementName
Controller name and location
For example, HP 8 INT Port SAS/SATA HBA in Slot 3
CIM_ManagedSystemElement
Name
Controller Serial Number
OperationalStatus[0]
Overall status of the Array System and attached
devices. This is calculated as per the algorithm
described in the HP SAS HBA Profile.
 0 (Unknown)
 2 (OK)
 3 (Degraded)
 6 (Error)
CIM_LogicalElement
CIM_EnabledLogicalElement
EnabledDefault
2 (Enabled)
EnabledState
5 (Not Applicable)
RequestedState
12 (Not Applicable)
CIM_System
CreationClassName
HPSAS_ArraySystem
NameFormat
Other
IdentifyingDescriptions
Other Vendor Specific Name
OtherIdentifyingInfo
Controller Serial Number
CIM_ComputerSystem
Dedicated
 Dedicated[0]: 3 (Storage)
 Dedicated[1]: 15 (Block Server)
16-3-2 HPSAS_ArrayController
HPSAS_ArrayController represents the controller. There is one instance per HBA.
Table 16-3 Class: HPSAS_ArrayController (CIM_ComputerSystem)
Property name
Property implementation
CIM_ManagedElement
