15-3-101 HPSA_SCSIInitiatorTargetLogicalUnitPath
The following class instance is created only with SAS controllers supporting multipath-supported
firmware and configured in dual domain mode.
Table 15-101 Class: HPSA_SCSIInitiatorTargetLogicalUnitPath
Property name
Property implementation
Initiator
HPSA_ISASSCSIProtocolEndpoint
Target
HPSA_TSASSCSIProtocolEndpoint
LogicalUnit
HPSA_StorageExtent
State
 0 (unknown) if the path status cannot be
ascertained
 2 (active) if the path is active and healthy
 5 (path Error) path has an error condition
 3 (passive) path is healthy but is not active or is the
standby path
15-3-102 HPSA_EncSASPortEncProtocolEndPoint
(Association)
Table 15-102 Class: HPSA_EncSASPortEncProtocolEndpoint (Association)
Property name
Property implementation
Antecedent
HPSA_EncSASPort
Dependent
HPSA_EncProtocolEndpoint
15-3-103 HPSA_ArraySystemEncProtocolEndpoint
(Association)
Table 15-103 Class: HPSA_ArraySystemEncProtocolEndpoint (Association)
Property name
Property implementation
Antecedent
HPSA_ArraySystem
Dependent
HPSA_EncProtocolEndpoint
15-3-104 HPSA_ArraySystemConnectivityCollection
(Association)
