HP Insight Management WBEM Providers 9.4 for Microsoft Windows Data Sheet

Table 2-14 Class: HP_SystemXNCFirmware
Property name
Property implementation
IdentityInfoValue
HPQ:<XNC firmware component specific_code>
Examples:
 HPQ: CPLD-P66-SPI
 HPQ: CPLD-P66-MAINIO
 HPQ: CPLD-P66-UPPERCPU
 HPQ: CPLD-P66-LOWERCPU
 HPQ: FMP-P66-UPPERXNC
 HPQ: FMP-P66-LOWERXNC
 HPQ: CPLD-P66-UPPERXNCFPGA
 HPQ: CPLD-P66-LOWERXNCFPGA
 HPQ: CPLD-P66-SFF
 HPQ: CPLD-P66-PCIEIO
 HPQ: CPLD-P66-PCIEXIO
Note: Either PCIe or Combo PCIe/PCI-X component
instance will be available at a time on the server.
HP_SystemXNCFirmware
2-3-13 HP_ SystemXNCElementFirmwareIdentity
HP_ SystemXNCElementFirmwareIdentity extends the class CIM_ElementSoftwareIdentity and
associates the HP_ComputerSystem and HP_SystemXNCFirmware instances.
The following properties are implemented.
Table 2-15 Class: HP_SystemXNCElementFirmwareIdentity
Property name
Property implementation
CIM_Dependency
CIM_ElementSoftwareIdentity
UpgradeCondition
3 (Owner Upgradeable)
ElementSoftwareStatus
 ElementSoftwareStatus[0]: 6 (Installed)
 ElementSoftwareStatus[1]: 2 (Current)
HP_SystemXNCElementFirmwareIdentity
Antecedent
ref: HP_SystemXNCFirmware
Dependent
ref: HP_ComputerSystem
2-3-14 HP_SystemXNCInstalledFirmwareIdentity
HP_SystemXNCInstalledFirmwareIdentity extends the class CIM_InstalledSoftwareIdentity and
associates the HP_ComputerSystem instance and an HP_SystemXNCFirmware instance.
