Table 15-70 Class: HPSA_SCSIProtocolControllerStorageVolume (CIM_ProtocolControllerForUnit)
Property name
Property implementation
Antecedent
HPSA_SCSIProtocolController
Dependent
HPSA_StorageVolume
DeviceAccess
2 (Read Write)
DeviceNumber
Device LUN number
15-3-71 HPSA_FirmwareArraySystem (Association)
Table 15-71 Class: HPSA_FirmwareArraySystem (CIM_ElementSoftwareIdentity)
Property name
Property implementation
Antecedent
HPSA_Firmware
Dependent
HPSA_ArraySystem
ElementSoftwareStatus
 ElementSoftwareStatus[0]: 2 (Current)
 ElementSoftwareStatus[1]: 6 (Installed)
15-3-72 HPSA_StorageEnclosureProcessorEnclosur
eFirmware (Association)
Table 15-72 Class: HPSA_StorageEnclosureProcessorEnclosureFirmware (CIM_ElementSoftwareIdentity)
Property name
Property implementation
Antecedent
HPSA_EnclosureFirmware
Dependent
HPSA_StorageEnclosureProcessor
ElementSoftwareStatus
 ElementSoftwareStatus[0]: 2 (Current)
 ElementSoftwareStatus[1]: 6 (Installed)
15-3-73 HPSA_DiskDriveDiskDriveFirmware
(Association)
Table 15-73 Class: HPSA_DiskDriveDiskDriveFirmware (CIM_ElementSoftwareIdentity)
Property name
Property implementation
Antecedent
HPSA_DiskDriveFirmware
Dependent
HPSA_DiskDrive
