Table 15-40 Class: HPSA_ConnectivityCollection
Property name
Property implementation
Description
"Protocol End point for Port: + <Port> + on Box: + <
Box Number> + connected to + <Cntrl DeviceID>
Where Cntrl DeviceID is DeviceID property of the
instance of HPSA_PortController to which this enclosure
Port is connected to.
Port is the unique identification number of the Enclosure
port in use
Box Number is the box number relative to active port
ElementName
<Cntrl DeviceID>:<Port Number>:<Box Number>
Where Cntrl DeviceID is DeviceID property of the
instance of HPSA_PortController to which this enclosure
Port is connected to.
Port Number is the unique identification number of the
Enclosure port in use
Box Number is the box number relative to active port
ConnectivityStatus
 0 (unknown) if the path status cannot be
ascertained
 2 (Connectivity/Up) if the path is active and
healthy
 3 (No Connectivity/Down) path has an error
condition
 32768 (Connectivity/Passive) path is healthy but is
not active or is the standby path
15-3-41 HPSA_ArraySystemRedundancySet
(Association)
Table 15-41 Class: HPSA_ArraySystemRedundancySet (CIM_ConcreteIdentity)
Property name
Property implementation
SameElement
HPSA_RedundancySet
SystemElement
HPSA_ArraySystem
15-3-42 HPSA_StorageVolumeStorageSetting
(Association)
Table 15-42 Class: HPSA_StorageVolumeStorageSetting (CIM_ElementSettingDate)
Property name
Property implementation
ManagedElement
HPSA_StorageVolume
