HP Insight Management WBEM Providers 9.4 for Microsoft Windows Data Sheet

HP Confidential
Table 15-39 Class: HPSA_ISASPort
Property name
Property implementation
CIM_EnabledLogicalElement
EnabledDefault
2 (Enabled)
RequestedState
12 (Not Applicable)
CIM_LogicalDevice
SystemnCreationClassName
HPSA_ArraySystem
SystemName
The property value of HP_ArraySystem.name
CreationClassName
HPSA_ISASPort
DeviceID
HPSA PortController.DeviceIDport #, where
HPSA_PortController.deviceID is the DeviceID property
of the instance of HPSA_PortController associated to
this instance via the association
HPSA_PortControllerISASPort, and port # is the port
number for the port. This is the same value that is
concatenated to the caption and related properties. An
example of a array controller with two external ports
is:
 PH77MW3991:1E
 PH77MW3991:2E
CIM_LogicalPort
UsageRestriction
4 (Not restricted)
PortType
94 (SAS)
15-3-40 HPSA_ConnectivityCollection
The following class instance is created only with SAS controllers supporting multipath supported
firmware and configured in dual domain mode.
Table 15-40 Class: HPSA_ConnectivityCollection
Property name
Property implementation
InstanceID
Opaque Key
Caption
Same value as Caption property of the instance of
HPSA_EncProtocolEndpoint associated to this instance
via the association
HPSA_EncProtocolEndPointConnectivityCollection
