HP Insight Management WBEM Providers 9.4 for Microsoft Windows Data Sheet

HP Confidential
Table 15-38 Class: HPSA_EncSASPort
Property name
Property implementation
OperationalStatus
2 (OK)
For multipath supported firmware implementations, the
status of the port is OK, and the status of the path is the
only element that can be detected.
CIM_EnabledLogicalElement
EnabledDefault
2 (Enabled)
EnabledState
5 (Not Applicable)
RequestedState
12 (Not Applicable)
CIM_LogicalDevice
SystemnCreationClassName
HPSA_ArraySystem
SystemName
The property value of HP_ArraySystem.name
CreationClassName
HPSA_EncSASPort
DeviceID
Opaque Key
CIM_LogicalPort
UsageRestriction
4 (Not restricted)
PortType
94 (SAS)
15-3-39 HPSA_ISASPort
This class is generated only if the SAS controller has multipath-supported firmware.
Table 15-39 Class: HPSA_ISASPort
Property name
Property implementation
CIM_ManagedElement
Caption
Port port #, where port # is the port number (for
example, 1E, 2E, and so on)
ElementName
Port port #, where port # is the port number (for
example, 1E, 2E, and so on)
CIM_ManagedSystemElement
OperationalStatus
2 (OK)
For multipath supported firmware implementations, the
status of the port is OK, and the status of the path is the
only thing that can be detected.
