HP Insight Management WBEM Providers 9.4 for Microsoft Windows Data Sheet

HP Confidential
Table 15-38 Class: HPSA_TSASPort
Property name
Property implementation
OperationalStatus
2 (OK)
For multipath supported firmware implementations, the
status of the port is OK, and the status of the path is the
only element that can be detected.
CIM_EnabledLogicalElement
EnabledDefault
2 (Enabled)
EnabledState
5 (Not Applicable)
RequestedState
12 (Not Applicable)
CIM_LogicalDevice
SystemnCreationClassName
HPSA_ArraySystem
SystemName
The property value of HP_ArraySystem.name
CreationClassName
HPSA_TSASPort
DeviceID
The same value as the
HPSA_TSASSCSIProtocolEndpoint.Name property of
the instance associated through
HPSA_ISASPortISASSCSIPE.
CIM_LogicalPort
UsageRestriction
4 (Not restricted)
PortType
94 (SAS)
15-3-38 HPSA_EncSASPort
This class is generated only if the SAS controller connected to the enclosure has multipath-supported
firmware.
Table 15-38 Class: HPSA_EncSASPort
Property name
Property implementation
CIM_ManagedElement
Caption
Port:<unique_index>, where unique_index is a unique
index across all ports on a storage enclosure
ElementName
Port:<unique_index>, where unique_index is a unique
index across all ports on a storage enclosure
CIM_ManagedSystemElement
