HP Insight Management WBEM Providers 9.4 for Microsoft Windows Data Sheet

HP Confidential
Table 15-37 Class: HPSA_ISASSCSIProtocolEndpoint
Property name
Property implementation
Caption
Protocol Endpoint for xxx, where xxx is the value
populated in the caption property of the instance of
HPSA_TSASPort associated to this instance via the
association HPSA_TSASPortTSASSCSIPE
ElementName
Protocol Endpoint for xxx, where xxx is the value
populated in the caption property of the instance of
HPSA_TSASPort associated to this instance via the
association HPSA_TSASPortTSASSCSIPE
CIM_ManagedSystemElement
Name
The same value as the DeviceID property of the
instance of HPSA_ISASPort associated to this instance
through the association HPSA_ISASPortISASSCSIPE.
CIM_LogicalElement
CIM_EnabledLogicalElement
CIM_ServiceAccessPoint
SystemnCreationClassName
HPSA_ArraySystem
SystemName
The property value of HPSA_ArraySystem.name
CreationClassName
HPSA_TSASSCSIProtocolEndpoint
CIM_ProtocolEndpoint
ProtocolIFType
1 (other)
OtherTypeDescription
SCSI
CIM_SCSIProtocolEndpoint
Role
2 (initiator)
15-3-37 HPSA_TSASPort
This class is generated only if the SAS controller connected to the disk drive has multipath-supported
firmware.
Table 15-38 Class: HPSA_TSASPort
Property name
Property implementation
CIM_ManagedElement
Caption
Port unique_index, where unique_index is a unique
index across all ports on a single drive
ElementName
Port unique_index, where unique_index is a unique
index across all ports on a single drive
CIM_ManagedSystemElement
