HP Insight Management WBEM Providers 9.4 for Microsoft Windows Data Sheet

HP Confidential
Table 15-35 Class: HPSA_TSASSCSIProtocolEndpoint
Property name
Property implementation
Name
HPSA DiskDrive.DeviceID:unique value, where HPSA
DiskDrive.DeviceID is the DeviceID property of the
instance of HPSA_DiskDrive associated to this instance
via the association HPSA_DiskDriveTSASSCSIPE, and
unique value is a unique value across all instances of
HPSA_TSASSCSIProtocolEndpoint. For example, a dual
port disk has two instances of
HPSA_TSASSCSIProtocolEndpoint with the name
properties set to:
 PH77MW3991:0:0
 PH77MW3991:0:1
CIM_LogicalElement
CIM_EnabledLogicalElement
EnabledDefault
2 (Enabled)
RequestedState
12 (Not Applicable)
CIM_ServiceAccessPoint
SystemnCreationClassName
HPSA_ArraySystem
SystemName
The property value of HP_ArraySystem.nam
CreationClassName
HPSA_TSASSCSIProtocolEndpoint
CIM_ProtocolEndpoint
ProtocolIFType
1 (Other)
OtherTypeDescription
SCSI
CIM_SCSIProtocolEndpoint
Role
3 (Target)
HPSA_TSASSCSIProtocolEndpoint
Path
Redundancy path status:
 0 (Unknown)
 2 (Active)
 3 (Passive)
 5 (Path Error)
15-3-35 HPSA_EncProtocolEndPoint
HPSA_EncProtocolEndPoint represents each port on SAS Enclosure. This class is generated only if the
SAS controller connected to the Enclosure has multipath-supported firmware.
Table 15-36 Class: HPSA_EncProtocolEndpoint
Property name
Property implementation
