Table 15-29 Class: HPSA_ArraySystemLocation (HP_Location)
Property name
Property implementation
ElementName
Controller name and location
Examples:
 Smart Array in Slot 3, for internal
 MSA500 in SystemCab03, for external
CIM_Location
Name
Opaque key
PhysicalPosition
Opaque key
HP_Location
ElementLocationTag
 PCI Slot Number—When ‗Adapter‘ is specified in
ElementLocationTagDesc
 Chassis Name—When ‗Chassis‘ is specified in
ElementLocationTagDesc
ElementLocationTagDesc
 23 (Adapter)—For internal HBAs
 3 (Chassis)—For External Storage systems
LocationInformation[0]
For internal HBAs: PCI Slot number
Examples:
 3—PCI Slot 3
 0—Embedded on Motherboard
 Not required for External Storage systems
LocationInfoDesc[0]
 3 (PCI Slot)—For internal HBAs
 1(Mezzanine Slot) – For Blade Systems
 Not required for External Storage Systems
HPSA_ArraySystemLocation
15-3-29 HPSA_DiskDriveLocation
HPSA_DiskDriveLocation represents a location string for the disk drive.
Table 15-30 Class: HPSA_DiskDriveLocation (HP_Location)
Property name
Property implementation
CIM_ManagedElement
Caption
Controller name, Drive Type and Disk Location
For example, Smart Array E500 Physical Drive – Port:
1E Box 1 Bay: 5
Description
Controller name, Drive Type and Disk Location
For example, Smart Array E500 Physical Drive—Port:
1E Box 1 Bay: 5
