Table 15-23 Class: HPSA_SCSIProtocolEndpoint (CIM_SCSIProtocolEndpoint)
Property name
Property implementation
CIM_ProtocolEndpoint
ProtocolIFType
0 (Unknown)
CIM_SCSIProtocolEndpoint
ConnectionType
The supported connection type for this endpoint
For example: 3(Parallel SCSI) for SCSI controllers
8(SAS) for SAS controllers
1 (Other)
OtherConnectionType
The connection type, if ConnectionType is "Other"
Role
4 (Both Initiator and Target)
HPSA_SCSIProtocolEndpoint
15-3-23 HPSA_SCSIProtocolController
HPSA_SCSIProtocolController represents a view of SCSI resources on the Array Controller.
Table 15-24 Class: HPSA_SCSIProtocolController (CIM_SCSIProtocolController)
Property name
Property implementation
CIM_ManagedElement
ElementName
Controller name and location (for example, Smart
Array in Slot 3)
CIM_ManagedSystemElement
OperationalStatus[0]
Operational status of the controller:
 0 (Unknown)
 2 (OK)
 6 (Error)
CIM_LogicalElement
CIM_EnabledLogicalElement
EnabledDefault
2 (Enabled)
EnabledState
5 (Not applicable)
RequestedState
12 (Not applicable)
CIM_LogicalDevice
CreationClassName
HPSA_SCSIProtocolController
DeviceID
Opaque key
SystemCreationClassName
HPSA_ArraySystem
SystemName
HPSA_ArraySystem.Name
