Table 15-21 Class: HPSA_StorageSetting (CIM_StorageSetting)
Property name
Property implementation
DataRedundancyMin
 1 (RAID 0, RAID 5, RAID 6, RAID 50)
 2 (RAID 1+0)
DeltaReservationGoal
0
DeltaReservationMax
0
DeltaReservationMin
0
NoSinglePointOfFailure
 FALSE—RAID 0
 TRUE—RAID 1+0, RAID 5, RAID 6
PackageRedundancyGoal
 0 (RAID 0)
 1 (RAID 1+0, RAID 5)
 2 (RAID 6, RAID 50)
PackageRedundancyMax
 0 (RAID 0)
 1 (RAID 1+0, RAID 5)
 2 (RAID 6, RAID 50)
PackageRedundancyMin
 0 (RAID 0)
 1 (RAID 1+0, RAID 5)
 2 (RAID 6, RAID 50)
HPSA_StorageSetting
15-3-21 HPSA_DriveCage
HPSA_DriveCage represents the drive cage assembly and backplane within a storage enclosure.
There can be multiple instances within a duplexed enclosure.
Table 15-22 Class: HPSA_DriveCage (CIM_PhysicalPackage)
Property name
Property implementation
CIM_ManagedElement
ElementName
Port <m> Box <n>, where <m> is the name of the port
this drive cage is connected and <n> is the box
number. For example, Port J3 Box 1
CIM_ManagedSystemElement
Name
Serial Number of drive cage
When serial number is not available, this field is left
empty
OperationalStatus
Operational Status of the DriveCage
CIM_PhysicalElement
CreationClassName
HPSA_DriveCage
Manufacturer
Drive Cage Vendor string
