Table 15-14 Class: HPSA_DAPort (CIM_DAPort)
Property name
Property implementation
CIM_ManagedSystemElement
OperationalStatus[0]
Port status:
 0 (Unknown)
 2 (OK)
 6 (Error)
CIM_LogicalElement
CIM_EnabledLogicalElement
EnabledDefault
2 (Enabled)
EnabledState
5 (Not Applicable)
RequestedState
12 (Not Applicable)
CIM_LogicalDevice
CreationClassName
HPSA_DAPort
DeviceID
Opaque key
SystemCreationClassName
HPSA_ArraySystem
SystemName
HPSA_ArraySystem.Name
CIM_LogicalPort
UsageRestriction
2 (Front-End Only)
PortType
 82(PCI)
 83(PCI-x)
The provider displays 82 (PCI) not 83(PCI-x). The
provider currently cannot display the 83 value for PCI-X
controllers.
CIM_DAPort
HPSA_DAPort
15-3-14 HPSA_SPIPort
HPSA_SPIPort represents the front-end port for an external Storage Subsystem. SPI implies that the
subsystem is connected through SCSI Parallel Interface to the Host.
Table 15-15 Class: HPSA_SPIPort (CIM_SPIPort)
Property name
Property implementation
CIM_ManagedElement
ElementName
Storage System name and location (for example,
MSA500 in SystemCab03)
CIM_ManagedSystemElement
