15-3-12 HPSA_PortController
HPSA_PortController represent the HBA in the host system. There is one instance per HBA. This class is
not implemented for external subsystems (for example, MSA500).
Table 15-13 Class: HPSA_PortController (CIM_PortController)
Property name
Property implementation
CIM_ManagedElement
ElementName
Controller name and location (for example, Smart
Array in Slot 3)
CIM_ManagedSystemElement
CIM_LogicalElement
CIM_EnabledLogicalElement
EnabledDefault
2 (Enabled)
EnabledState
5 (Not Applicable)
RequestedState
12 (Not Applicable)
CIM_LogicalDevice
CreationClassName
HPSA_PortController
DeviceID
Controller serial number
SystemCreationClassName
HPSA_ArraySystem
SystemName
HPSA_ArraySystem.Name
CIM_Controller
CIM_PortController
ControllerType
1 (Other)
OtherControllerType
SCSI, SAS/SATA
HPSA_PortController
15-3-13 HPSA_DAPort
HPSA_DAPort represents the front-end port for an HBA in the host system. Direct Attached implies that
the array controller is attached to a local bus on the host (for example, PCI).
Table 15-14 Class: HPSA_DAPort (CIM_DAPort)
Property name
Property implementation
CIM_ManagedElement
ElementName
Controller name and location (for example, Smart
Array in Slot 3)
