HP Insight Management WBEM Providers 9.4 for Microsoft Windows Data Sheet

HP Confidential
Table 15-12 Class: HPSA_StorageEnclosureProcessor (CIM_ComputerSystem)
Property name
Property implementation
CIM_ManagedElement
ElementName
Port <m1, m2> Box <n>, where <m1> is the active port,
<m2> is the passive port number and <n> is the box
number. For dual port SAS disks, both port numbers
should be displayed
CIM_ManagedSystemElement
Name
Opaque Key
OperationalStatus[0,1, 2, 3 ]
Operational status for enclosure and associated power
supplies, fans and sensors. The use of
OperationalStatus is described in the HP Storage
Enclosure Profile. Index values are populated as
follows.
 Index[0]—Enclosure status:
○ 0 (Unknown)
○ 2 (OK)
○ 3 (Degraded)
○ 6 (Error)
 Index[1]—Fan status (See Profile)
 Index[2]—Power Supply status (See Profile)
 Index[3]—Temp Sensor Status (See Profile)
CIM_LogicalElement
CIM_EnabledLogicalElement
EnabledDefault
2 (Enabled)
EnabledState
5 (Not Applicable)
RequestedState
12 (Not Applicable)
CIM_System
CreationClassName
HPSA_StorageEnclosureProcessor
NameFormat
Other
IdentifyingDescriptions[0]
Other Vendor Specific Name
OtherIdentifyingInfo[0]
Port Number:BoxNumber enclosure is attached to(for
example, 1E:1). For dual port SAS disks, both port
numbers appear.
CIM_ComputerSystem
Dedicated[0]
2 (Other)
OtherDedicatedDescriptions[0]
SDE—Indicates Storage Device Enclosure
HPSA_StorageEnclosureProcessor
