Table 15-5 Class: HPSA_DiskDrive (CIM_DiskDrive)
Property name
Property implementation
NegotiatedSpeed
See HP Smart Array Profile
Identify()
See HP Smart Array Profile
SSDTotalPowerOnHours
This is the total number of hours that the Solid State
Disk has been powered on.
SSDPercentageEnduranceUsed
This is the Physical Drive Solid State Percent Endurance
Used.
SSDLifeRemaining
This is the Solid State drive life remaining days until
wear out.
SSDWearStatus
This is the wearout status of the Solid State drive
15-3-5 HPSA_StorageExtent
HPSA_StorageExtent represents the consumable storage that is available on a disk drive. There is one
instance per disk drive.
Table 15-6 Class: HPSA_StorageExtent (CIM_StorageExtent)
Property name
Property implementation
CIM_ManagedElement
ElementName
Disk location. This property holds the relative ports and
box information. (For example, Port: <m1, m2> Box:
<n1, n2>, where <m1> is the active port, <m2> is the
passive port number and <n1> is the box number
relative to active port and <n2> is the box number
relative to passive port.)
Caption
Disk location (For example, Port: <m1, m2> Box: <n>,
where <m1> is the active port, <m2> is the passive
port number and <n> is the box number where in the
drive is placed.)
CIM_ManagedSystemElement
Name
Serial number of drive
OperationalStatus[0]
Operational Status for the disk drive
 0 (Unknown)
 2 (OK)
 5 (Predictive Failure)
 6 (Error)
CIM_LogicalElement
CIM_EnabledLogicalElement
EnabledDefault
2 (Enabled)
EnabledState
5 (Not Applicable)
