HP Insight Management WBEM Providers 9.4 for Microsoft Windows Data Sheet

HP Confidential
Table 15-4 Class: HPSA_StorageVolume (CIM_StorageVolume)
Property name
Property implementation
NameFormat
2 (VPD83NAA6)
PackageRedundancy
 0 (RAID 0)
 1 (RAID 1+0, RAID 5, RAID 1 (ADM), RAID 1+0
(ADM))
 2 (RAID 6, RAID 50)
CIM_Storagevolume
HPSA_Storagevolume
Accelerator
See HP Smart Array Profile
Deleteable
See HP Smart Array Profile
FaultTolerance
See HP Smart Array Profile
OSName
Corresponding OS name for this volume.
If the volume/logical disk failed, then this variable d
displays empty
StripeSize
See HP Smart Array Profile
Identify()
See HP Smart Array Profile
PhysicalDrvMultipathAccess
Uint16 PhysicalDrvMultipathAccess – Value –
Valuemap
 1 (not supported)—Not supported by Array
Firmware
 2 (not configured)—Supported by Array Firmware
but not configured
 3 (configured redundant)—Volume is configured
with redundant physical paths on all physical drives
that make up the volume
 4 (configured non-redundant)—Volume is
configured with redundant paths but is currently not
redundant possibly due to failure of 1 or more
paths or a configuration error
Primordial
False—Can create and delete this element
LogicalVolumeType
Uint16 LogicalVolumeType – Value – Valuemap
 0 (Unknown)
 1 (Other)
 2 (Data LUN)
 3 (Cache LUN)
RelatedLUN
The related LUN will report the corresponding primary
or cache LUN number of the Storage Volume.
15-3-4 HPSA_DiskDrive
HPSA_DiskDrive represents the Hard Drives connected to Smart Array controllers.
